12025A AC Axial Fan
Reliable AC Cooling for Industrial and Electrical Applications
The 12025A AC Axial Fan is a robust industrial cooling solution designed for stable airflow, long service life, and reliable performance in demanding electrical and industrial environments.
With a standard 120 × 120 × 26 mm form factor, this model is widely used in control cabinets, power supplies, inverters, communication equipment, and industrial ventilation systems where continuous operation and durability are critical.
Durable Structure for Long-Term Operation
The fan frame is manufactured from aluminum alloy, providing excellent mechanical strength and heat resistance, while the impeller is made of engineering plastic, ensuring balanced rotation and low operational noise.
A dual ball bearing system enables smooth operation and supports a rated service life of 50,000 hours at 40°C, making it suitable for long-term, maintenance-free use.
Stable Performance Under Harsh Conditions
Designed to operate in challenging environments, the 12025A AC Axial Fan supports:
-
Operating temperature: −40°C to +75°C
-
Storage temperature: −50°C to +85°C
These characteristics allow the fan to perform reliably in industrial, outdoor, or enclosed electrical systems.
Electrical & Airflow Performance
Running on 230V / 50Hz AC power, the fan delivers a well-balanced combination of airflow and pressure:
-
Airflow up to 108.7 m³/h
-
Static pressure up to 45 Pa
-
Noise level as low as 38 dBA
This makes it an ideal choice for applications requiring efficient cooling without excessive noise.
Compliance & Application
The environmental performance of this fan complies partially with GJB 1423-1992, subject to the detailed specifications of the product datasheet.
Typical applications include:
-
Electrical control cabinets
-
Industrial power equipment
-
HVAC auxiliary cooling
-
Communication and automation systems
For customized voltage, performance tuning, or OEM requirements, Senharfans provides professional technical support and flexible solutions.
